Cabinet Hinge - Easy Installation Bridge Shaped Door Hinges

Trust Cabinet Hinge for all your installation needs!

Our strong and reliable hinges make installation easy, so you can get the job done right the first time!

Features

Strong and Reliable: Made of manganese steel, which is known for its strength and durability. This material is able to withstand heavy use and harsh environmental conditions, making it ideal for use in a variety of applications. The thickening of the base for strong firmness also increases the load-bearing area of the base, making the cabinet door and hinge more secure. Additionally, multiple thick rivets provide a stable connection, making the structure more stable and durable.

Wide Application: Designed to fit a range of door thicknesses. The 3-inch hinges are suitable for doors with a thickness of 12-16mm, while the 170°large size hinges are suitable for doors with a thickness of 0-40mm. This makes them suitable for use in a wide range of cabinets and other applications.

Easy Installation: Cabinet Hinge Bridge Shaped Door Hinges are designed for easy installation and alignment. The hinges come with pre-drilled holes for secure mounting, and the installation is simple and straightforward. Additionally, the hinges come with adjustable screws, which allow you to make small adjustments to ensure the door is aligned properly. This makes it easy to ensure the door is perfectly aligned and secure.

How to install:

1. Measure the thickness of the door panel

2. Pay attention to the closing direction of the hinge

3. Position the hinge on the door panel

4. Straighten and position the hinge on the door panel. When installing, tighten one screw first without tightening it. Once the position is determined, tighten all other screws

Specifications

Type: 3-inch thick(without hydraulic),4-inch thick(without hydraulic),5-inch thick(with hydraulic),170°Large size (without hydraulic),170°Large size (with hydraulic)

Material: Manganese steel

Surface treatment: Nickel plating

Installation method: No hole opening required, fixed with screw-in screws
